Meet the New

WasteX Biochar Equipment

Experience 2x the durability and higher processing capacity in our most efficient decentralized carbonizer.

Endorsed by Carbon Standards International

dMRV by WasteX

Automated Temp Control

Clean Emissions


Our Technology

Carbonizer Model Y 2.4 is an autothermal continuous-type screw reactor developed to produce high-quality biochar with minimal energy use and labor.

2.4 black painted transparent.webp

What's New in Y2.4?

 2x Durability​

SS310 upgrades for high-temp zones: extend parts life and halves maintenance cost.

Better Fuel Efficiency

Upgraded burner and piping design for efficient fuel and syngas combustion.

​+20%

Capacity

Redesigned hopper extender & sliding gate boosts feed consistency.

Redesigned burner and piping system and auto fan control improve heat and pressure control.

Better Temp & Pressure Control

Lower PAH

Improved gas management prevents PAH (polycyclic aromatic carbon) condensation.

Mechanical Engineering Tools

Contact us for more technical details

WasteX digital MRV (Android app)

A screenshot of WasteX's dMRV app

Our clients are equipped with an Android app to digitally measure, report, and verify (dMRV) biochar production and application using WasteX's carbonizer for the purpose of carbon credits.

Features:

  • Biochar producer registration and full process recording for the purpose of carbon credits

  • Carbon impact and credits recording and calculation

  • Self-service materials

Endorsement for Carbon Credits

Logo of Carbon Standards International

WasteX's biochar equipment and dMRV app are endorsed by the Carbon Standards International for the Global Artisan C-Sink standard.

white grey background.jpg
EQUIPMENT
Certificate of endorsement from Carbon Standards International for WasteX's biochar pyrolysis equipment

Feedstock Processed by WasteX Biochar Machine

WasteX biochar machine can convert readily available organic materials such as agricultural waste and forestry residues into biochar. Examples include wood chips, rice husk, corn cobs, used poultry bedding, and many more.

Wood chips

Rice husk

Corn cobs

Used poultry bedding

Used poultry bedding

Key Feedstock Requirements

  • Min. calorific value of 15 MJ/kg

  • Maximum moisture content of 15 wt% (<15 wt% recommended for more optimal performance)

  • Particle size of 30 mm or below

  • Minimum length to width ratio of 0.6

  • Pourable and free flowing

Worldwide Implementations

*Implementations using Y2.3

Equipment Specifications

Parameters
Unit
Value
Dimensions
3.5 x 3.0 x 2.4
meter
Weight
~1050
kg
Peak power rating
5.5
kW
Burner temperature
400-800
°C
Pyrolysis temperature
500-650
°C
Processing capacity
30 - 90
kg/hour
Biochar conversion
30-40%
%
Biochar production rate
10-36
kg/hour
Fuel/feedstock ratio
10-15%*
%
Manpower requirements
2-4
manhours/day

*Assuming 8 hours continuous operations

Frequently Asked Questions

Ready to produce biochar with our pyrolysis machine?

Our implementation consultant will reach out to you shortly!
